*AstraHP Coated* Bits&Bits 425-CM125 – 1/8″ Spiral Compression Bit – 1/4″ Shank
$49.99
Designed for CNC applications requiring high feed rates and compression cuts. They work well for double-sided melamine or laminated material.
- AstraHP Coated
- Solid Carbide
- Tip Diameter: 1/8″
- Shank Diameter: 1/4″
- Length of cut: 5/8″
- Spiral change: 0.12″
- Overall Length: 2-1/2″
- Made in the USA
- Available in 1″ Length of Cut.
In stock
Solid Carbide Compression Router Bit 2 flute (2+2) with a cutting tip diameter of 1/8″ and a 5/8″ cut length. These tools are Astra Coated which allows higher speed & feed rates as well as extended tool life & increased lubricity in abrasive material. Our compression bits are designed for CNC applications requiring high feed rates and compression cuts. They work well for double-sided melamine or laminated material.
What is a Compression Bit?
A Compression bit is a spiral bit that combines up cut and down cut action into one bit. The cutting tip pulls the fibers and chips up towards the center of the workpiece. The rest of the bit is cutting and pushing wood fibers down, also towards the center of the workpiece. This up cut down cut action is what leaves a sharp, clean edge on both edges of your workpiece. The up cut flutes on a compression spiral bit is typically equal to the diameter of the bit, for example, a 1/2" diameter has a up cut flute of 1/2". The transition point is referred to as the 'Spiral Change'. We also offer several sizes of compression bit with a shorter up cut flute length which is referred to as a short flute compression (also called a mortise style compression bit). The slow-mo video clip below was shot by none other that Jonathan Katz-Moses and shows the cutting action of the compression bit. You can clearly see the difference between the up and down cut portions of the bit.
How do I use the Compression bit correctly?
In order to properly use a compression bit to get it's full benefit, your initial cut needs to be slightly deeper than the upcut flute length, which as mentioned above is usually equal to the diameter of the bit. When used correctly, you shouldn't see any tear out or chip out on the edges. In the video above, the bit on the left is seen cutting not deep enough to pass the up cut flutes. The bit on the right is set at the correct depth.
Can you use a Compression Bit in a router?
Yes, all of our compression and spiral bits can be used in a CNC, handheld router or a router table.
| Weight | 0.07 lbs |
|---|---|
| Brand | Bits & Bits |
| Shank | 1/4" |
| Cut Diameter | 1/8" (.125") |
| Cut Length | 5/8" |
| Cut Style | Compression |
Speeds & Feeds
This data serves as a general guidance only.
Soft/Hard Woods/ MDF – Spindle Speed- RPM: 16,000RPM – Feed Rate – IPM : 40-50″
Max Cut depth per pass 1/8″
1 review for *AstraHP Coated* Bits&Bits 425-CM125 – 1/8″ Spiral Compression Bit – 1/4″ Shank
Add a review
New, unused in-stock tools may be returned within 30 days of delivery for a full refund. Made-to-order tools such as engraving cutters with custom tip sizes are subject to a 20% restock fee if returned. The buyer is responsible for return shipping costs unless the return is the result of our error (i.e. you received an incorrect or defective item). Beyond 30 days, we reserve the right to offer refunds or store credit at our discretion, with the exception of warranty related requests. You can also exchange any unused item for one of our other tools. You will be responsible for shipping charges on any exchanges unless in error on our part.If your order arrives damaged in any way, please email us as soon as possible at [email protected] with your order number and a photo of the condition.
For more information, see our Returns and Refunds page.
For more information see our returns and refunds page..
Defective Items
We are committed to ensuring all of our products are of high quality and will replace or refund items that we determine to be defective. In the event you believe you have a defective tool, please call us or email us at [email protected]. Include your order number and as much info as you can about your setup, i.e., CNC, router, speeds and feeds, material you’re cutting, etc. In most cases of what seemed to be a defective tool, we have been able to help a customer with proper settings or techniques for efficient use.Related products
